300X300X45D BLK MAX JUNC RRJPVC FAB - DWV RUBBER RING

DN300 x 45° BlackMAX® Equal Junction FFF DWV RRJ Branch (PVC Fab)



Enquire

Enquire



GWR2430045R

Overview
  • Australian Made
  • Abrasion and Corrosion Resistant
  • Treet root intrusion resistance
  • Smooth internal bore for hydraulic performance
  • Low embodied energy for environmental benefits
Additional Information Requires 2 x DN300 BlackMAX® Rubber Ring Iplex Code: GERSEW300
Product Properties
Size001228
RatingSN8 / Non Pressure
Length
Degree45
Primary Material003
UOMEA
Joint TypeRRJ
Rubber Ring MaterialStyrene Butadiene Rubber (SBR)
ColourBlack external wall with white internal bore
Minimum Cover DepthSUBJECT TO VARIATION BY THE REGULATORY AUTHORITY. No vehicular loading - 300mm. With vehicular loading: Under driveways 450mm; Sealed roadways 600mm; Unsealed roadways 750mm; Embankment conditions 750mm; Construction equipment loading 500mm - 750mm
Average Number of Joints per Litre-Iplex Lubricant28
Allowable Operating Temperature - Degrees(Up to 50°C) - Re-rating is applied >30°C
Socket Deflectionup to 2°
MarkingsManufactures name and/or registered trademark > Nominal Size > Stiffness> PVC > Date of Manufacture > Place of Manufacture
Dimensions
Size 001228
Weight 16.00
Standards & Accrediations
Product StandardAS/NZS1260 PVC-U pipes and fittings for drain, waste and vent applications' & 'AS/NZS 5065 'Polyethylene and polypropylene pipes and fittings for drainage and sewerage applications'
