DN600 x dn375 x 45° BlackMax® Reducing Junction FFF RRJ (PP Fab)

Enquire

Enquire



GR25603745

Overview
  • Australian Made
  • Abrasion and Corrosion Resistant
  • Treet root intrusion resistance
  • Smooth internal bore for hydraulic performance
  • Low embodied energy for environmental benefits
Additional Information Requires 2 x DN600 BlackMAX® Rubber Ring Iplex Code: GERSEW600 and 1 x DN375 BlackMAX® Rubber Ring Iplex Code GERSEW375
Product Properties
Size 600MM
Rating SN8 / Non Pressure
Length BLANK
Degree 45
Primary Material POLYPROPYLENE
UOM EACH
Joint Type RRJ
Rubber Ring Material Styrene Butadiene Rubber (SBR)
Colour Black external wall with yellow internal bore
Minimum Cover Depth SUBJECT TO VARIATION BY THE REGULATORY AUTHORITY. No vehicular loading - 300mm. With vehicular loading: Under driveways 450mm; Sealed roadways 600mm; Unsealed roadways 750mm; Embankment conditions 750mm; Construction equipment loading 500mm - 750mm
Average Number of Joints per Litre-Iplex Lubricant 14
Allowable Operating Temperature - Degrees Allowing Operating Temperature. Up to 50℃ Re rating is applied for Temperatures >30℃
Socket Deflection up to 2°
Markings Manufactures name and/or registered trademark > Nominal Size > Stiffness> PP > Date of Manufacture > Place of Manufacture
Dimensions
Size 600MM
Weight 50
600X375X45D BLK MAX RED JUNCFF RRJ PP FAB
Standards & Accreditations
Product Standard AS/NZS 5065 'Polyethylene and polypropylene pipes and fittings for drainage and sewerage applications'
