Product properties
- Size
- 100MM
- Rating
- SN8
- Length
- BLANK
- Degree
- 88
- Primary Material
- PVC
- Joint Type
- RRJ
- Colour
- Grey
- Minimum Cover Depth
- Where no subject to vehicular loading - min. cover depth 300mm | Where subject to vehicular loading min. cover depth |Under Driveways 450mm | In sealed roadways 600mm | In unsealed roadways 750mm
- Average Number of Joints per Litre-Iplex Lubricant
- 25
- Allowable Operating Temperature - Degrees
- 60°C
- Unprotected UV Exposed
- 2 Years
Mechanical properties
- Density - Specific Gravity
- 1.47kg/m3
- Ultimate Tensile Strength
- 52MPa
- Yield Strain
- 5.50%
- Compressive Strength
- 66MPa
- Tensile Modulus
- 2750MPa
- Hardness Shore D
- 85
- Poissons Ratio
- 0.38
- Ring Bending Modulus - 3mins
- 3200MPa
- Ring Bending Modulus - 50yrs
- 1400MPa
Thermal properties
- Coefficient of Thermal Expansion
- 7 x 10-5/oC
- Thermal Conductivity
- 0.138W/m.K
- Specific Heat
- 1047 J/kg/oC
- Vicat Softening Temperature
- 75oC
- Flammability
- Will not support combustion
- Fire Index - Ignitability
- 8
- Fire Index - Smoke Developed
- 8
- Fire Index - Heat Evolved
- 1
Standards & Accreditations
- Product Standard
- AS/NZS 1260 "PVC-U pipes and fittings for drain, waste and vent applications"
- Product Approvals and Appraisals
-
WaterMark Certification: 23900
WSSA PA 1404 "PLASTEC Injection Moulded PVC-U DWV Fittings" - Environmental Accreditation
- Best Environmental Practice PVC
