100 DWV OVERFLOW RELIEF CAP ATS5200.501-2009
D128100DORC
Overview
- The Iplex Overflow Relief Cap is an anti-infiltration device (ORC), which seals against stormwater infiltrating sewer drains
during flood conditions, whilst providing effective vent and overflow relief functions.
Venting:
In normal operation the ORC device acts as a vent
to prevent water syphoning out of the trap
Sealing
The ORC device provides a watertight seal
against ingress in flood prone areas
Overflow
In the event of a surcharge the ORC device will
eject from the gully riser allowing free relief
as per a conventional ORG
Product Properties
Size/Diameter
100MM
Primary Material
PVC
Joint Type
SWJ
Colour
White
Minimum Cover Depth
Where no subject to vehicular loading - min. cover depth 300mm | Where subject to vehicular loading min. cover depth | Under Driveways 450mm | In sealed roadways 600mm | In unsealed roadways 750mm
Cure Time for Solvent Weld Joints
24 hours
Mechanical Properties
Density - Specific Gravity
1.47
kg/m3
Ultimate Tensile Strength
52MPa
Yield Strain
0.055
Yield Stress
151.25MPa
Compressive Strength
66MPa
Tensile Modulus
2750MPa
Hardness Shore D
85
Poissons Ratio
0.38
Thermal Properties
Coefficient of Thermal Expansion
7 × 10⁻⁵/°C
Thermal Conductivity
0.138W/m.K
Specific Heat
1047 J/kg/°C
Vicat Softening Temperature
75°C
Flammability
Will not support combustion
Fire Index - Ignitability
8
Fire Index - Smoke Developed
8
Fire Index - Spread of Flame
0
Fire Index - Heat Evolved
1
Dimensions
Size/Diameter
100MM
Carton Quantity
30
Standards & Accreditations
Product Standard
AS/NZS 1260
Environmental Accreditation
ApprovalMark - Compliance: Certificate No. BEP-PVC 0037
Warranty
1 Year
