300 AVK Ball Check, FL PN16 Series 53/35
Enquire Download Product Sheet
C5532.30
Overview
- Self-cleaning construction, where the ball rotates during operation eliminating the risk of impurities getting stuck on the ball
- Full bore ensures low pressure loss and minimum back pressure
- Compact design and low weight
Additional Information
AVK Reference Code 53300505012
Product Data Sheet
View
Product Properties
Size
300MM
Rating
PN16
Length
BLANK
Primary Material
DUCTILE IRON
UOM
EACH
Rubber Ring Material
EPDM (RRJ)
Lining Specification
Thermal bonded polymeric coatings AS/NZS 4158
Allowable Operating Pressure - 20 Degrees Celsius
PN16
Markings
AVK
Industry Specific Names
AVK
Alternative Iplex Products
PVC, PE, GRP
Mechanical Properties
Density - Specific Gravity
7.10
kg/m3
Ultimate Tensile Strength
400MPa
Hardness Shore D
250
Dimensions
Size
300MM
Standards & Accreditations
Product Standard
Face to face according to AS 4794
Flange drilling to AS 4078
Flange drilling to AS 4078
