250 AVK Gate Valve, Resilient Seated FL PN25 ACC Series 57/80
Enquire Download Product Sheet
C5231.25
Overview
- Reduced weight and environmentally friendly
- Valve designed for us up to 70℃
- Sturdy wedge design
- Triple safety stem sealing system
Additional Information
AVK Reference Code 57250803748120
Product Data Sheet
View
Product Properties
Size
250MM
Rating
PN25
Length
BLANK
Primary Material
DUCTILE IRON
UOM
EACH
Rubber Ring Material
EPDM (RRJ)
Lining Specification
Thermal bonded polymeric coatings AS/NZS 4158
Allowable Operating Pressure - 20 Degrees Celsius
PN25
Markings
AVK
Industry Specific Names
AVK
Alternative Iplex Products
PVC, PE, GRP
Mechanical Properties
Density - Specific Gravity
7.10
kg/m3
Ultimate Tensile Strength
400MPa
Hardness Shore D
250
Dimensions
Size
250MM
Standards & Accreditations
Product Standard
AS/NZS 2628.2
Flange drilling to AS 4087 B6
Flange drilling to AS 4087 B6
Product Approvals and Appraisals
Standards Mark AS2638.2
