250X200 PN10 PRESS S1 BUSH MFMF RED CAT5

DN250 x DN200 Raccord PVC-U Reducing Bush MF SWJ



Enquire

Enquire



P00510250200

Overview
  • SWJ High Pressure PVC
Product Properties
Size 250MM
Rating PN10
Length BLANK
Primary Material PVC
UOM EACH
Joint Type SWJ
Colour Dark Grey
Minimum Cover Depth Not subject to vehicular loading 300mm |With vehicular loading, not in roadways 450mm | With vehicular loading, beneath sealed roadways 600mm |With vehicular loading, beneath unsealed roadways 750mm
Cure Time for Solvent Weld Joints >15℃ 24hrs | 0-15℃ 48hrs
Allowable Operating Temperature - Degrees 50 DEG
Allowable Operating Pressure - 20 Degrees Celsius PN10 @ 20 deg
Mechanical Properties
Ultimate Tensile Strength 52MPa
Yield Strain 0.055
Compressive Strength 66MPa
Tensile Modulus 3200MPa
Hardness Shore D 85
Poissons Ratio 0.38
Design Stress 11MPa
Thermal Properties
Coefficient of Thermal Expansion 7 x 10-5/℃
Thermal Conductivity 0.138W/m.K
Specific Heat 1047 J/kg/℃
Vicat Softening Temperature 75℃
Flammability will not support combustion
Fire Index - Ignitability 7
Fire Index - Smoke Developed 9
Fire Index - Heat Evolved 2
Dimensions
Size 250MM
Carton Qty 72
Standards & Accreditations
Product Standard AS/NZS 1477:2017 PVC pipes and fittings for pressure applications
POP Documents PIPA Guidelines & Notes (iplex.com.au)
Warranty 2 Year
