200X45D PN9 PRESS BEND FF L/R CAT12
P01220045
Overview
Product Properties
Size/Diameter
200MM
Degree
45
Primary Material
PVC
Joint Type
SWJ
Colour
White
Minimum Cover Depth
Not subject to vehicular loading 300mm | With vehicular loading, not in roadways 450mm | With vehicular loading, beneath sealed roadways 600mm | With vehicular loading, beneath unsealed roadways 750mm
Cure Time for Solvent Weld Joints
>15°C 24 hours | 0–15°C 48 hours
Mechanical Properties
Density - Specific Gravity
1.43
kg/m3
Ultimate Tensile Strength
52MPa
Yield Strain
0.055
Yield Stress
176MPa
Compressive Strength
66MPa
Tensile Modulus
3200MPa
Hardness Shore D
85
Poissons Ratio
0.38
Design Stress
11MPa
Thermal Properties
Coefficient of Thermal Expansion
7 × 10⁻⁵/°C
Thermal Conductivity
0.138W/m.K
Specific Heat
1047 J/kg/°C
Vicat Softening Temperature
75°C
Flammability
will not support combustion
Fire Index - Ignitability
7
Fire Index - Smoke Developed
9
Fire Index - Spread of Flame
0
Fire Index - Heat Evolved
2
Dimensions
Size/Diameter
200MM
Weight
1.58 kg
Standards & Accreditations
Product Standard
AS/NZS 1477 'PVC pipes and fittings for pressure applications'
Environmental Accreditation
ApprovalMark - Compliance: Certificate No. BEP-PVC 0037
Warranty
1 year
