Overview
- Australian Made
- BEP PVC - Manufactured from Best Environmental Practice PVC
- Installation economics
- Operation efficiencies
- Corrosion resistant
- Light weight
- Electrically nonconductive
Product Properties
Size/Diameter
125 mm
Length
4.0 m
Primary Material
PVC
Joint Type
Solvent Weld Joint
Colour
Orange
Allowable Operating Temperature - Degrees
60°C
Minimum Radius of Curvature
37.5 m
Socket Deflection
0
Unprotected UV Exposed
3 months
Maximum Support Spacing of Pipe Graded
1.2 m
Markings
Material/Size/PN or SN rating/Applicable Australian Standard
Mechanical Properties
Ultimate Tensile Strength
52MPa
Yield Strain
0.055
Compressive Strength
66MPa
Tensile Modulus
3200MPa
Hardness Shore D
85
Poissons Ratio
0.38
Design Stress
11MPa
Ring Bending Modulus - 3mins
3000MPa
Ring Bending Modulus - 50yrs
1200MPa
Thermal Properties
Coefficient of Thermal Expansion
7 × 10⁻⁵/°C
Thermal Conductivity
0.138 W/m.K
Specific Heat
1047 J/kg/°C
Vicat Softening Temperature
>70°C
Flammability
Will not support combustion
Fire Index - Ignitability
7
Fire Index - Smoke Developed
9
Fire Index - Spread of Flame
0
Fire Index - Heat Evolved
2
Dimensions
Size/Diameter
125 mm
Weight
12
Crate Quantity
38
Crate Weight
456.04 kg
Socket Length
115 mm
Socket Mouth Diameter
140.8 mm
Socket Root Diameter
139.4 mm
Wall Skin Thickness
0.4 mm
Standards & Accreditations
Product Standard
Referenced Australian electrical and telecommunications product standards include: AS/NZS 2053 (various parts)
AS/NZS 4296
AS/NZS 5033
AS 4702
AS/NZS 4296
AS/NZS 5033
AS 4702
