DN600 x 5.5m PN35 Irontite Blue ZN/AL Ductile Iron Pipe RRJ Seal Coat

Enquire    Download Product Sheet

Enquire



C3011.0600SC

Overview
  • High Strength
  • Impact Resistant
  • Tremendous Burst Strength
  • Ease of Installation
Product Data Sheet Artboard View
Product Properties
Size 600MM
Rating PN35
Length 5.5M
Primary Material DUCTILE IRON
UOM LENGTHS
Joint Type RRJ
Rubber Ring Material EPDM (RRJ)
Colour BLUE/RED BAND
Coating Specification Zinc/Alloy 400g/m3
Lining Specification General Purpose Cement (GP)
Allowable Operating Temperature - Degrees 50℃
Allowable Operating Pressure - 20 Degrees Celsius PN 35
Minimum Radius of Curvature 138m
Socket Deflection 2.5°
Maximum Support Spacing of Pipe Graded 5.5m
Markings Jindal SAW|Iplex Irontite ®|DN|PN|AS/NZS|StandardsMark|Batch Number
Industry Specific Names Griptite®, Nortite®, Crevet Superlite®
Alternative Iplex Products PVC, PE, GRP
Mechanical Properties
Density - Specific Gravity 7.10 kg/m3
Ultimate Tensile Strength 420MPa
Hardness Shore D 230
Poissons Ratio 0.3
Design Stress 7.1
Ring Bending Modulus - 3mins 165000N/mm2
Thermal Properties
Coefficient of Thermal Expansion 12.5 x 10-6/℃
Dimensions
Size 600MM
Inner Diameter 647mm
Weight 990kg
Wall Thickness 10.2mm
Socket Depth 127mm
600 PN35 IRONTITE BLUE ZN/AL RX5.5M DI CL PIPE SEALCOAT
Standards & Accreditations
Product Standard AS/NZS 2280 Ductile Iron Pipes and Fittings
AS/NZS 4087 Metallic Flanges for Waterworks Purposes
Product Approvals and Appraisals Standards Mark SMK0950
WSAA Apprasial PA 1802
