C3015.0600
DN600 x 5.5m PN20 Irontite Blue ZN/AL Ductile Iron Pipe RRJ Seal Coat
Quick Menu
Overview
Product Data Sheet
View
Product Properties
Size/Diameter
600 mm
Rating
PN20
Length
5.5 m
Primary Material
DUCTILE IRON
Joint Type
RRJ
Rubber Ring Material
EPDM (RRJ)
Colour
BLUE/GREEN BAND
Coating Specification
Zinc/Alloy 400g/m3
Lining Specification
Cement
Allowable Operating Temperature - Degrees
50°C
Allowable Operating Pressure - 20 Degrees Celsius
PN20
Socket Deflection
2.5°
Mechanical Properties
Density - Specific Gravity
7.1
kg/m3
Ultimate Tensile Strength
450MPa
Poissons Ratio
0.3
Ring Bending Modulus - 3mins
165000N/mm² MPa
Thermal Properties
Coefficient of Thermal Expansion
12.5 × 10⁻⁶/°C
Dimensions
Size/Diameter
600 mm
Weight
719.6 kg
Wall Thickness
9.0 mm
Socket Depth
127 mm
Standards & Accreditations
Product Standard
AS/NZS 2280
Product Approvals and Appraisals
Standards Mark SMK0950
WSAA Apprasial PA 1802
WSAA Apprasial PA 1802
