DN500 x 5.5m PN35 Irontite Red ZN/AL Ductile Iron Pipe RRJ CA Lined

System:
Metals
Sub System:
Irontite Ductile Pipe
Product Code:
C3012.0500

Features

  • High Strength
  • Impact Resistant
  • Tremendous Burst Strength
  • Ease of Installation
Product Data Sheet
Link

Product properties

Size
500MM
Rating
PN35
Length
5.5M
Primary Material
DUCTILE IRON
UOM
LENGTHS
Joint Type
RRJ
Rubber Ring Material
EPDM (RRJ)
Colour
RED/RED BAND
Coating Specification
Zinc/Alloy 400g/m3
Lining Specification
Cement
Allowable Operating Temperature - Degrees
50°C
Allowable Operating Pressure - 20 Degrees Celsius
PN35
Socket Deflection
2.5

Mechanical properties

Density - Specific Gravity
7.10kg/m3
Ultimate Tensile Strength
450MPa
Poissons Ratio
0.3
Ring Bending Modulus - 3mins
165000N/mm2

Thermal properties

Coefficient of Thermal Expansion
12.5 x 10-6/oC

Product dimensions

Size
500MM
ID
531mm
Weight
742.5kg
Wall Thickness
8.8mm
Socket Depth
127mm
Max Socket Nominal OD
646mm

Standards & Accreditations

Product Standard
AS/NZS 2280
Product Approvals and Appraisals
Standards Mark SMK0950
WSAA Apprasial PA 1802
