Learn more about our
DN375 x 5.5m PN35 Irontite Red ZN/AL Ductile Iron Pipe RRJ CA Lined
Enquire Download Product Sheet
C3012.0375
Overview
- High Strength
- Impact Resistant
- Tremendous Burst Strength
- Ease of Installation
Product Data Sheet
View
Product Properties
Size
375MM
Rating
PN35
Length
5.5M
Primary Material
DUCTILE IRON
UOM
LENGTHS
Joint Type
RRJ
Rubber Ring Material
EPDM (RRJ)
Colour
RED/RED BAND
Coating Specification
Zinc/Alloy 400g/m3
Lining Specification
Calcium Aluminate Cement (CA)
Allowable Operating Temperature - Degrees
50℃
Allowable Operating Pressure - 20 Degrees Celsius
PN 35
Minimum Radius of Curvature
138m
Socket Deflection
2.5°
Maximum Support Spacing of Pipe Graded
5.5m
Markings
Jindal SAW|Iplex Irontite ®|DN|PN|AS/NZS|StandardsMark|Batch Number
Industry Specific Names
Griptite®, Nortite®, Crevet Superlite®
Alternative Iplex Products
PVC, PE, GRP
Mechanical Properties
Density - Specific Gravity
7.10
kg/m3
Ultimate Tensile Strength
420MPa
Hardness Shore D
230
Poissons Ratio
0.3
Design Stress
7.1
Ring Bending Modulus - 3mins
165000N/mm2
Thermal Properties
Coefficient of Thermal Expansion
12.5 x 10-6/℃
Dimensions
Size
375MM
Inner Diameter
406mm
Weight
477.6kg
Wall Thickness
7mm
Socket Depth
127mm
Standards & Accreditations
Product Standard
AS/NZS 2280 Ductile Iron Pipes and Fittings
AS/NZS 4087 Metallic Flanges for Waterworks Purposes
AS/NZS 4087 Metallic Flanges for Waterworks Purposes
Product Approvals and Appraisals
Standards Mark SMK0950
WSAA Apprasial PA 1802
WSAA Apprasial PA 1802
