DN300 x 5.5m PN20 Irontite Blue ZN/AL Ductile Iron Pipe RRJ Seal Coat

Enquire    Download Product Sheet

Enquire



C3015.0300

Overview
Product Data Sheet Artboard View
Product Properties
Size 300MM
Rating PN20
Length 5.5M
Primary Material DUCTILE IRON
UOM LENGTHS
Joint Type RRJ
Rubber Ring Material EPDM (RRJ)
Colour BLUE/GREEN BAND
Coating Specification Zinc/Alloy 400g/m3
Lining Specification Cement
Allowable Operating Temperature - Degrees 50℃
Allowable Operating Pressure - 20 Degrees Celsius PN20
Socket Deflection 3.5
Mechanical Properties
Density - Specific Gravity 7.10 kg/m3
Ultimate Tensile Strength 450MPa
Poissons Ratio 0.3
Ring Bending Modulus - 3mins 165000N/mm2
Thermal Properties
Coefficient of Thermal Expansion 12.5 x 10-6/℃
Dimensions
Size 300MM
Inner Diameter 323mm
Wall Thickness 5mm
Socket Depth 102mm
300 PN20 IRONTITE LITE ZN/ALX5.5M DI CL RRJ PIPE SEAL COAT
Standards & Accreditations
Product Standard AS/NZS 2280 "Ductile Iron Pipes and Fittings"
Product Approvals and Appraisals Standards Mark SMK0950
WSAA Apprasial PA 1802
