C3011.0200SC
DN200 x 5.5m PN35 Irontite Blue ZN/AL Ductile Iron Pipe RRJ Seal Coat
Quick Menu
Overview
- High Strength
- Impact Resistant
- Tremendous Burst Strength
- Ease of Installation
Product Data Sheet
View
Product Properties
Size/Diameter
200 mm
Rating
PN35
Length
5.5 m
Primary Material
DUCTILE IRON
Joint Type
RRJ
Rubber Ring Material
EPDM (RRJ)
Colour
BLUE/RED BAND
Coating Specification
Zinc/Alloy 400g/m3
Lining Specification
General Purpose Cement (GP)
Allowable Operating Temperature - Degrees
50°C
Allowable Operating Pressure - 20 Degrees Celsius
PN 35
Minimum Radius of Curvature
98 m
Socket Deflection
3.5°
Maximum Support Spacing of Pipe Graded
5.5 m
Markings
Jindal SAW | Iplex Irontite® | DN | PN | AS/NZS | StandardsMark | Batch Number
Alternative Iplex Products
PVC, PE, GRP
Mechanical Properties
Density - Specific Gravity
7.1
kg/m3
Ultimate Tensile Strength
420MPa
Hardness Shore D
230
Poissons Ratio
0.3
Design Stress
7.1
Ring Bending Modulus - 3mins
165000N/mm² MPa
Thermal Properties
Coefficient of Thermal Expansion
12.5 × 10⁻⁶/°C
Dimensions
Size/Diameter
200 mm
Weight
189.8
Wall Thickness
5.0 mm
Socket Depth
102 mm
Standards & Accreditations
Product Standard
AS/NZS 2280 Ductile Iron Pipes and Fittings
AS/NZS 4087 Metallic Flanges for Waterworks Purposes
AS/NZS 4087 Metallic Flanges for Waterworks Purposes
Product Approvals and Appraisals
Standards Mark SMK0950
WSAA Apprasial PA 1802
WSAA Apprasial PA 1802
