400 AVK Coupling Universal Long 8 Bolt 410-436 PN16 SS Bolts Series 601

Enquire    Download Product Sheet

Enquire



C32604.410436

Overview
  • Non restrained
  • Angular deflection of ±3 degrees (total 6 degrees)
  • For water and sewer applications to max 60&#8451
Additional Information AVK Reference Code: 6014360014312
Product Data Sheet Artboard View
Product Properties
Size 375MM
Rating PN16
Length BLANK
Primary Material DUCTILE IRON
UOM EACH
Rubber Ring Material EPDM (RRJ)
Lining Specification Thermal bonded polymeric coatings AS/NZS 4158
Markings NIBF
Industry Specific Names Griptite®, Nortite®, Superlite®
Alternative Iplex Products PVC, PE, GRP
Mechanical Properties
Density - Specific Gravity 7.10 kg/m3
Ultimate Tensile Strength 400MPa
Hardness Shore D 250
Dimensions
Size 375MM
410-436 UNI COUP LONG(8 BOLT)SS BOLTING SERIES 601 - AVK
Standards & Accreditations
Product Standard AS/NZS 4998:2009 bolted unrestrained mechanical couplings for waterworks purposes
AS/NZS 4020
Product Approvals and Appraisals Standards Mark Licence SMKP 25236
