Back

GSR105375

BlackMax®/SewerMax® PVC Cap DN375 FF Max RRJ Grey

Overview Product Properties Mechanical Properties Dimensions

Overview

Watertight closure
RRJ
Ease of jointing/push fit
Lightweight

Additional Information Requires 1 x DN375 BlackMax® Rubber Ring Iplex Code: GERSEW375

Product Properties

Size/Diameter 375 mm

Rating Non Pressure

Primary Material PVC

Joint Type RRJ

Rubber Ring Material Styrene Butadiene Rubber (SBR)

Colour Grey external wall with white internal bore

Allowable Operating Temperature - Degrees Up to 50°C. Re-rating is applied for temperatures > 30°C

Socket Deflection up to 2°

Markings Iplex > BlackMax®/SewerMax® > Cap RRJ > DN375 > PVC > Date of Manufacture > RELN > GSR105375

Mechanical Properties

Density - Specific Gravity 1.45 kg/m³

Dimensions

Size/Diameter 375 mm

Weight 10 kg
