Overview
- 1000mm to 600mm transition for efficient chamber access and cover support.
- Engineered strength suitable for roadway installations.
- Integrated ladder supports enhance safety and accessibility.
- Lightweight injection moulded construction simplifies handling and installation.
- Corrosion-resistant design enables final surface level adjustment and long-term durability.
Additional Information
Add 1 x 600 mm Ring GERSEW600
Product Data Sheet
View
Line Drawing Dimensions
View
Product Properties
Size/Diameter
1000 mm
Rating
Non Pressure
Length
1.0 m
Primary Material
Other
Joint Type
RRJ
Colour
Black & Grey
Allowable Operating Temperature - Degrees
Up to 50 oC, rerating is applied > 20 oC
Markings
Iplex, WAVIN, Lankhorst, EziPit, Cone, PP, Date of Manufacture, Batch and Mould Identity Code & No, DN1000 x dn600 FF RRJ, EN 13598-2
Mechanical Properties
Density - Specific Gravity
0.9
kg/m3
Poissons Ratio
0.45
Thermal Properties
Coefficient of Thermal Expansion
15 x 10-5 / o C
Dimensions
Size/Diameter
1000 mm
Weight
31.0 kg
Standards & Accreditations
Product Standard
WSA137
