125 LD COND PIPE SWJ X6M ORG ELEC
P4001256
Overview
- Australian Made
- BEP PVC - Manufactured from Best Environmental Practice PVC
- Installation economics
- Operation efficiencies
- Corrosion resistant
- Light weight
- Electrically nonconductive
Product Properties
Size/Diameter
125MM
Length
6.0M
Primary Material
PVC
Joint Type
Solvent Weld Joint
Colour
Orange
Allowable Operating Temperature - Degrees
60°C
Allowable Operating Pressure - 20 Degrees Celsius
600kPa
Minimum Radius of Curvature
37.5m
Socket Deflection
0
Unprotected UV Exposed
3 months
Maximum Support Spacing of Pipe Graded
1.2m
Maximum Support Spacing of Pipe Vertical
2.0m
Markings
Material/Size/PN or SN rating/Applicable Australian Standard
Mechanical Properties
Ultimate Tensile Strength
52MPa
Yield Strain
0.055
Compressive Strength
66MPa
Tensile Modulus
3200MPa
Hardness Shore D
85
Poissons Ratio
0.38
Design Stress
11MPa
Ring Bending Modulus - 3mins
3000MPa
Ring Bending Modulus - 50yrs
1200MPa
Thermal Properties
Coefficient of Thermal Expansion
7 × 10⁻⁵/°C
Thermal Conductivity
0.138 W/m.K
Specific Heat
1047 J/kg/°C
Vicat Softening Temperature
>70°C
Flammability
Will not support combustion
Fire Index - Ignitability
7
Fire Index - Smoke Developed
9
Fire Index - Spread of Flame
0
Fire Index - Heat Evolved
2
Dimensions
Size/Diameter
125MM
Weight
10.1 kg
Crate Quantity
38
Crate Weight
383.84kg
Socket Length
115
Socket Mouth Diameter
140.7
Socket Root Diameter
139.4
Wall Skin Thickness
0.4
Standards & Accreditations
Product Standard
Referenced Australian electrical and telecommunications product standards include: AS/NZS 2053 (various parts)
AS/NZS 4296
AS/NZS 5033
AS 4702
AS/NZS 4296
AS/NZS 5033
AS 4702
