Overview
- Australian Made
- BEP PVC - Manufactured from Best Environmental Practice PVC
- Installation economics
- Operation efficiencies
- Corrosion resistant
- Tree root intrusion resistant
- Leakage elimination
Product Data Sheet
View
Product Properties
Size/Diameter
375 mm
Length
3.0M
Primary Material
PVC
Joint Type
RRJ
Rubber Ring Material
EPDM polymer, which conforms to the requirements of AS 1646
Colour
Light grey
Allowable Operating Temperature - Degrees
60°C
Minimum Radius of Curvature
112.5 m
Socket Deflection
1°
Unprotected UV Exposed
2 years yr
Maximum Support Spacing of Pipe Graded
1.5 m
Maximum Support Spacing of Pipe Vertical
3.00 m (Reference AS/NZS 2033, applicable to above ground installations)
Markings
Material/Size/PN or SN rating/Applicable Australian Standard
Mechanical Properties
Ultimate Tensile Strength
52 MPa
Yield Strain
5.5%
Compressive Strength
66 MPa
Tensile Modulus
3200MPa
Hardness Shore D
85
Poissons Ratio
0.38
Design Stress
12.3MPa
Ring Bending Modulus - 3mins
3200MPa
Ring Bending Modulus - 50yrs
1400MPa
Thermal Properties
Coefficient of Thermal Expansion
7 × 10⁻⁵/°C
Thermal Conductivity
0.38 W·m⁻¹·K⁻¹
Specific Heat
1047 J/kg/°C
Vicat Softening Temperature
75°C
Flammability
Will not support combustion
Fire Index - Ignitability
8
Fire Index - Smoke Developed
8
Fire Index - Spread of Flame
0
Fire Index - Heat Evolved
1
Dimensions
Size/Diameter
375 mm
Weight
70.416
Crate Quantity
6
Crate Weight
422 kg
Wall Thickness
11.1 mm
Socket Length
154
Chamfer Length
23.0 mm
Standards & Accreditations
Product Standard
AS/NZS 1260 'PVC-U pipes and fittings for drain, waste and vent applications'
Environmental Accreditation
ApprovalMark - Compliance: Certificate No. BEP-PVC 0037
