Overview
- Australian made
- Lightweight
- Operational efficiencies
- High performance rubber ring joint
- Resistant to root intrusion
- Smooth internal bore
- Recyclable
Product Data Sheet
View
Product Properties
Size/Diameter
900 mm
Length
6.0 m
Primary Material
POLYPROPYLENE
Joint Type
RRJ
Rubber Ring Material
SBR
Colour
Black with yellow internal liner
Allowable Operating Temperature - Degrees
50 °C
Socket Deflection
2°
Unprotected UV Exposed
2 years
Markings
Iplex Pipelines, DN, SN8, PP, Date of Manufacture, BlackMAX®
Mechanical Properties
Density - Specific Gravity
0.9
kg/m3
Yield Strain
0.08
Yield Stress
31 MPa
Hardness Shore D
60
Poissons Ratio
0.45
Ring Bending Modulus - 3mins
1300 MPa
Ring Bending Modulus - 50yrs
342 MPa
Thermal Properties
Coefficient of Thermal Expansion
15 x 10⁻⁵ / ℃
Thermal Conductivity
0.22 W/m.K
Specific Heat
1700 J/kg/°C
Vicat Softening Temperature
157°C
Dimensions
Size/Diameter
900 mm
Weight
234
Crate Quantity
2
Crate Weight
515 kg
Socket Depth
432 mm
Witness Mark Detail
5th Rib
Standards & Accreditations
Product Standard
AS/NZS 5065 'Polyethylene and polypropylene pipes & fittings for drainage & sewerage applications'
Creep Ratio
3
