Product Properties
Size/Diameter
150 mm
Length
6.0 m
Primary Material
PVC
Joint Type
SWJ
Colour
White
Minimum Radius of Curvature
45 m
Socket Deflection
0
Unprotected UV Exposed
2 Years
Maximum Support Spacing of Pipe Graded
1.2 m
Markings
Material/Size/PN or SN rating/Applicable Australian Standard
Mechanical Properties
Yield Strain
0.055
Compressive Strength
66MPa
Tensile Modulus
3200MPa
Hardness Shore D
85
Design Stress
11MPa
Thermal Properties
Coefficient of Thermal Expansion
7 × 10⁻⁵/°C
Specific Heat
1047 J/kg/°C
Flammability
Will not support combustion
Fire Index - Spread of Flame
0
Dimensions
Size/Diameter
150 mm
Weight
28.543 kg
Crate Quantity
33
Socket Length
125 mm
Socket Mouth Diameter
160.8 mm
Socket Root Diameter
159.4 mm
Chamfer Length
3.0 mm
Standards & Accreditations
Environmental Accreditation
ApprovalMark - Compliance: Certificate No. BEP-PVC 0037
