100 PN12.5 PRESS S2 PIPE RRJX6M BLUE OPVC APOLLO BLUE

DN100 x 6m PN12.5 Apollo Blue Series 2 PVC-O Pipe Rieber RRJ (A Long description to test for the product description field text limitations up to 150)



Enquire

Enquire



PDRA12100

Overview
  • Australian Made
  • BEP PVC - Manufacutred from Best Environmental Practice PVC
  • Installation Economics
  • Operation Efficiences
  • Corrosion Resistant
  • Light weight
  • Excellent Toughness and Ductility
  • Large Internal Diameter and Smooth bore
Product Data Sheet Artboard View
Product Properties
Size001213
RatingPN12.5
Length659
Primary Material003
UOMLE
Joint TypeRRJ
Rubber Ring MaterialEPDM
ColourBlue
Minimum Cover DepthNot subject to vehicular loading 300mm |With vehicular loading, not in roadways 450mm | With vehicular loading, beneath sealed roadways 600mm |With vehicular loading, beneath unsealed roadways 750mm
Average Number of Joints per Litre-Iplex Lubricant42
Allowable Operating Temperature - Degrees50°C
Allowable Operating Pressure - 20 Degrees Celsius1200KPa
Minimum Radius of Curvature30m
Socket Deflection
Maximum Diametric Deflection - 50yrs7.50%
Unprotected UV Exposed2 Years
Product Certifications

www.iplex.com.au/resources-and-tools/white-pages/

Mechanical Properties
Density - Specific Gravity1.47kg/m3
Ultimate Tensile Strength52MPa
Yield Strain5.50%
Compressive Strength66MPa
Tensile Modulus4000MPa
Hardness Shore D85
Poissons Ratio0.38
Design Stress28MPa
Ring Bending Modulus - 3mins4000MPa
Ring Bending Modulus - 50yrs1800MPa
Thermal Properties
Coefficient of Thermal Expansion7 x 10-5/oC
Thermal Conductivity0.138W/m.K
Specific Heat1047 J/kg/oC
Vicat Softening Temperature>79°C
FlammabilityWill not support combustion
Fire Index - Ignitability2
Fire Index - Smoke Developed8
Fire Index - Heat Evolved2
Dimensions
Size 001213
ID 114.9mm
Weight 12.5kg
Crate Qty 36
Crate Weight 450kg
Wall Thickness 3.4mm
Socket Depth 150mm
Standards & Accreditations
Product StandardAS/NZS 4441
Product Approvals and AppraisalsStandardsMark Certification SMKP20188
POP DocumentsPIPA Guidelines & Notes (iplex.com.au)
Warranty1 Year
